Blizzard SCSI Kit MkIV

19th March 2021

Ever since I picked up my Blizzard 1230 MkIV card last year I’ve been hankering after the SCSI expansion for it. The Squirrel SCSI system I’ve been using for the past six months certainly works great but I really wanted to free up the PCMCIA port for other things.

Blizzard SCSI kits are pretty thin on the ground these days but after many months of searching I finally managed to get one. It came complete with the software disk, instruction manual, SCSI breakout port and even a 64MB SIMM!

Everything you get in the Blizzard SCSI Kit.

It’s in beautiful condition and if it wasn’t for the faded text on a couple of the stickers it could probably pass for being brand new.

Close-up of the 26-pin SCSI header on the board.

There are three connecters on the board. On the top there’s a 72-pin socket to accept a SIMM of up to 128Mb capacity.

26-pin SCSI header.

There’s also a 26-pin header for connecting the ribbon cable for the 25 pin female D-SUB SCSI port. Finally on the bottom there’s a 100 pin edge connecter which is used to connect the SCSI card to the 1230 MkIV accelerator card.

The business end of the card with a Symbios Logic SCSI Host adapter chip dated 1992.

Underneath the board there’s a single 100 pin edge connecter and a white insulating pad to prevent any short circuits when the card is installed.

View of the underside of the board. The large white area is insulating material to prevent short-circuits.

Specifications

In the mid 90’s these cards were pretty cutting edge and offered Amiga 1200 owners some impressive features. The manual proudly claims that it will “set new performance standards in its class”.

The headline specifications are listed below:

Fast SCSI-II DMA Controller for the Blizzard 1230-IV or Blizzard 1260 Turbo Boards.
Transmission rates up to 7Mb/s asynchronous and up to 10 Mb/s synchronous on the SCSI bus.
72-pin standard SIMM socket for memory expansion by up to 128Mb in addition to the memory already installed on the Blizzard Turbo Board. Completely auto-configuring.
Ability to connect 6 SCSI devices with ID’s between 0 and 7 (the Blizzard SCSI Card itself is device 0).

Fitting the SCSI Connecter Port

Fitting the card is a little more involved than the accelerator was as installing the rear-mounted SCSI port requires removing the floppy drive to gain access to the expansion port.

Expansion port blanking plate and the holes where the two floppy drive mounting screws fit.

There’s two screws holding the drive in place from the underside of the case, found next to the expansion port. The other screw is located inside the case along the lower edge of the drive just above the trapdoor. Once these have been removed the drive can be safely lifted to one side revealing the expansion port area.

Location of the three screws holding the floppy drive in place.

After removing the plastic blanking plate, the SCSI connecter slides into the vacant slot from the rear. If done correctly the hole in the metal plate should align with the hole in the Amiga case perfectly.

SCSI port connecter inserted into expansion slot.

The provided screw can then be inserted into the hole from the base of the Amiga and fastened into the threaded hole in the metal plate.

SCSI port fully fitted – you can see the securing screw on the base of the case next to the rubber foot.

This screw is the only thing that holds the port in place whilst inserting and removing SCSI cables so it needs to be securely fastened.

Metal plate now secured with the supplied screw.

It’s a pretty neat and surprisingly robust solution and looks almost factory fitted.

This is how the SCSI port looks once fitted. Also – I hadn’t noticed how corroded my mouse port was until I took this photo!

Fitting the SCSI Card

With the fitment of the SCSI port dealt with it was time for the main event – fitting the SCSI card.

View of the Blizzard 1230 MkIV and SCSI Kit IV installed in the trapdoor expansion bay.

The SCSI card needs to be married to the Accelerator card before it’s fitted into the slot. There simply isn’t enough room inside the case to attach the SCSI card once the accelerator has been installed. I took my time here as there’s only one way the two cards will successfully slot into place and I didn’t want to damage either by trying to force anything.

Another view of the Blizzard 1230 MkIV and SCSI Kit IV installed in the trapdoor expansion bay.

Once the two cards are correctly aligned the accelerator card (and only the accelerator card!) can be firmly pressed into its socket. Pushing the edge of the SCSI card might damage the edge connecter.

Close-up of how the ribbon cable connects to the SCSI card. Pin one is nearest the SIMM socket.

Pin 1 is next to the SIMM socket and the ribbon cable should be attached such that the red edge aligns with it. However in reality the SCSI cable will only fit one way due to how close the pins are to the circuit board.

View of the Blizzard 1230 MkIV Accelerator and SCSI MkIV cards from below.

Testing it all Works!

As always with an old upgrade like this I was quite anxious about whether it would actually work. After double-checking that everything was connected correctly I powered on my A1200 and waited. Thankfully a few moments later Workbench appeared and was reporting approximately 128Mb of Fast Ram available. Definitely a positive sign!

132,065,208 bytes free – a very promising sign.

Next I loaded up the SCSI Config software off the Blizzard Tools disk to see if my devices were being recognised. Sure enough both my Zip drive and CDROM appeared as unit 5 and 2 respectively. Happy days!

Checking to see if my SCSI devices were recognised using the Blizzard SCSI Config utility.

Although my devices were visible to the system, my discs weren’t showing up on Workbench yet. This was because they were still configured to use my Squirrel SCSI hardware. To get them working I edited the ‘tool types’ for my ZIP and CD mountlists in DEVS:DOSDrivers, setting the ‘DEVICE’ to ‘1230scsi.device’ for them both (the name of the Blizzard SCSI host adapter).

Editing the ZIP mountlist tool type to use my Blizzard 1230scsi.device.

A quick CTRL-A-A reboot and everything was working – my Zip drives, CDROM’s and Music CD’s were all recognised correctly.

Closing Thoughts

This has been another great addition to my A1200. Not only do I have all my SCSI peripherals working but now I have an extra 64Mb of Fast RAM to play with. Additionally my PCMCIA port is now left vacant so I’m free to explore the addition of a network card or maybe a card reader.

Is this the end for my Amiga 1200’s trapdoor expansions? For the time being, probably yes. I could replace the 64Mb SIMM fitted in both cards with 128Mb SIMM’s to give me a total of 256Mb. However my A1200 already has way more RAM than I ever had back in the day so not sure if that is really necessary. Mind you, if I see some RAM going cheap I’ll probably go for it.

There’s always the possibility of replacing the 1230 for an 040 or 060 accelerator (or even a PPC one). Unfortunately these expansions are obscenely expensive nowadays so that would be hard to justify. Besides, I think the 68030 is the sweet spot for performance versus compatibility for the Amiga. I never say never though…

Amiga Addict – A Brand New Monthly UK Amiga Magazine!

2nd March 2021

Steven

Amiga

4 Comments

Who would have thought that the beginning of 2021 would see the launch a brand new monthly UK Amiga magazine? But that’s exactly what has happened with the publication of ‘Amiga Addict’ magazine. Of course there are quite a few Amiga-centric mags out there now and I have covered these in the past but I believe this is the first UK Amiga mag and certainly the only one released on a monthly basis. Issue 1 was released in January, issue 2 in February and the March issue has just appeared on their website now too!

This slideshow requires JavaScript.

The cover design looks comfortingly familiar, and certainly wouldn’t have looked out of place on a 1980’s WH Smith shelf. At first glance it could easily be mistaken for a copy of Amiga Format but the magazine makers make no bones about the fact that they were inspired by all those great Amiga mags from the 80’s and 90’s.

Someone’s nicked my coverdisk!

I thought the tongue-in-cheek picture of a 3.5″ floppy disk with the message ‘What no coverdisk? was a particularly fun touch. It certainly brought a smile to my face along with fond memories of seeing this message under my coverdisks after peeling them off back in the day. It would have been awesome to have a coverdisk as an option with the first issue but I fully understand why this wasn’t practical.

The magazine itself is A4 sized and has a premium glossy cover with silk finished pages inside. Both issue 1 and 2 run to 55 pages in total and feature a number of adverts from the current Amiga scene too. I always enjoyed browsing the adverts to see what games and gizmos I could get for my Amiga back in the day and I still get that same enjoyment from doing the same thing now with Amiga Addict.

Contents Page.

A Look Inside Issue 1

Inside issue 1 there’s healthy mixture of gaming, news, letters, reviews, interviews and ‘how to’ articles. It aims to cater to all Amiga users whether they be using classic 68k machines, emulators or FGPA systems. I’ve only read issue one so far but I have to say I was really impressed with it.

The writing style is terrific and very entertaining and I could feel the passion that the authors have for the Amiga throughout their writing. It was refreshing to find a real sense of humour in a lot of the articles that constantly made me smile too. I do appreciate some light hearted banter in my magazines – it helps elevate them to something that I really look forward to, to lift my mood and provide some much needed escapism. This could well just be a British thing but it’s something I don’t find much of in the other current Amiga mags.

A review of the PageStream DTP software that is used to create some of the pages of Amiga Addict!

I found the reviews to be excellent; very informative and entertaining in equal measure. I discovered a couple of great new games that I was unaware of and proceeded to order them straight away. At the end of the day this is what it’s all about – helping to keep the Amiga community informed and thriving. Of course much of this info is probably available online… but it is likely spread across various social media and other retro oriented sites which can sometimes feel impossible to keep track of. Personally I think it’s fantastic to have all this info distilled into a single monthly publication. Something that I can read at my leisure without any political posts, irrelevant ads or trolls to annoy and distract me. Spoken like the true grumpy old man that I am.

What I personally find really impressive is that the entire magazine is actually laid out using PageStream on an Amiga X5000. You certainly couldn’t ask for a better demonstration that the Amiga is still relevant today! Suddenly I now how a strong hankering for an X5000 myself!

Anyway here’s a look at just few of the articles that can be found in the inaugural issue.

This slideshow requires JavaScript.

I’ve still got issue 2 to read and have just ordered issue 3 so am eagerly awaiting the arrival of that in the post soon!

If the magazine looks interesting to you then head over to the Amiga Addict website straight away and order yourself a copy – it deserves all the support it can get. Copies are available both digitally and physically and discounted subscriptions are available too!

How to use an Iomega Zip Drive with the Amiga A1200

16th September 2020

Steven

Amiga

7 Comments

In this post I’m going to explain just how you can use an Iomega Zip 100 Drive with an Amiga 1200. The software side of this will be applicable to other Amiga models too but the hardware required is specific to the Amiga 600/1200 series as it utilises the PCMCIA port.

A Little bit of history

Before I delve into the guide a little bit of history. Back in the early 1990’s the most common media format available to Amigan’s was the humble 3.5″ DS/DD Floppy Disk. HD floppy drives were available too but were expensive and only offered double the storage capacity anyway.

This was when Iomega launched their Zip 100 Drive, along with a new disk format that could hold a whopping 100MB. This was a big deal to me back then as standard Amiga floppies could only hold 880K of data and Hard Disk drives cost a fortune! The disks were very similar in size and shape to regular disks and about twice as thick as you can see in the photo below.

Zip 100 Disk next to a standard 3.5″ disk.

These drives were aimed at the PC and Apple Mac markets but enthusiasts quickly facilitated the use of them with Amigas too. There were three versions of this drive made that hooked up in one of three different ways; parallel port, SCSI and later a USB version too. However it is important to note that only one version is actually suitable for Amiga use and that is the SCSI version. (The parallel version can be made to work but it requires physically modifying the Amiga’s parallel port which is something I have no intention of doing).

If you have a big box Amiga there’s actually a fourth version – they made an Internal version of the drive with an ATAPI IDE interface but that’s a project for another time… if I ever get my own ‘big box’ Amiga system!

This is what the back of a SCSI Zip 100 drive should look like. If it doesn’t look like this then don’t buy it – it won’t work.

Now of course by todays standards 100MB is a trifling amount, my mobile phone has 256GB of storage for example. My Amiga 1200 also has an 8GB CF card so technically I don’t really need any more storage. However all that misses the point. In my eyes, to have an authentic Amiga experience and relive the 90’s you need to use the appropriate hardware. Besides, most of the fun of using retro computers is getting old stuff working again… not because you need to, but because you want to!

My ‘new’ Zip 100 Drive still sporting the ‘how to insert a disk’ sticker on the top.

Buying a Zip 100 Drive

Zip drives went out of production a long time ago so your only source is the second hand market now, which for most people will be eBay. There’s always a few on there in various conditions with prices ranging from around £40 to £120. Now of course what you buy is entirely up to you but from my own personal experience I’d say it is worth paying extra for a drive that has been fully tested and confirmed working. I tried the cheap and cheerful approach and ended up with three duds before I decided enough was enough and paid £90 for a fully tested one. Cheaper in the long run and a lot less hassle for sure!

New Old Stock (NOS) Zip 100 disks are still readily available.

The disks can be bought very cheaply and there’s plenty out there, even brand new and sealed. Expect to pay between £1.50 and £4 per disk depending on quantity being sold and whether they’re new or used. You can even pick yourself up some rainbow Zip disks and caddy boxes to store them all in!

Rainbow Zip 100 Disks.

Adding SCSI to the Amiga 1200

Despite it’s name, the SCSI.device on the A1200 is actually the internal IDE interface. That’s not going to work with our Zip drive so we need to get hold of a SCSI adapter of some kind. If you have a Blizzard trapdoor accelerator card then there was a SCSI expansion made for that. However these are pretty rare nowadays so I would recommend you pick up a Squirrel SCSI interface instead. These devices were made to slot into the Amiga 600/1200’s PCMCIA expansion port and opened up a whole new world of SCSI devices to Amiga enthusiasts.

Amiga Squirrel SCSI Device.

The Squirrel SCSI Interface was made by a company called HiSoft but other companies would often bundle it with their own products. I picked up mine as part of a Power Computing CD-ROM drive bundle. Interestingly Power Computing is still going strong, although not surprisingly they don’t sell anything for the Amiga any more.

Squirrel SCSI Adapter plugged into my A1200’s PCMCIA Expansion Port.

The Squirrel is just a small box that plugs into the PCMCIA port and has a short cable with a 50 pin male SCSI connector permanently wired into it. No matter whether you buy the Squirrel on its own or with another device we now have another issue.

No way our Squirrel SCSI is connecting to these out of the box…

The Zip drive has two D25 female connectors on the back but our only connector from the Squirrel is a male 50 pin Centronics plug. They don’t fit together so we need to get creative with our cabling. Ideally we would need a cable with a female 50 pin Centronics connector one end and a male D25 connector at the other but I was unable to locate one.

All the hardware needed to connect our Zip 100 Drive.

Fortunately there are still a variety of cables and connectors cheaply available. What I ended up having to do was get a male D25 to male 50 pin Centronics cable and a ‘gender changer’ connector. The latter is basically a double sided female 50-pin Centronics connector.

A closer look at the SCSI gender changer.

The gender changer allows us to join the two male connectors from the Squirrel and the D25-Centronics cable together as you can see in the next image.

Two male 50-pin Centronics cables connected by means of a gender changer.

SCSI Chains

So now we have our Squirrel SCSI Interface fitted with cables that can actually connect to our Zip 100 Drive. However, before actually connecting everything up we just need to check that Termination is enabled on our Zip drive.

Zip 100 Drive connected to Squirrel SCSI.

I’m not going to go into great detail here but suffice to say that SCSI (an acronym for Small Computer System Interface) is a system that allowed the daisy-chaining of multiple devices to a computer. To enable the computer to be able to identify each device in the chain they were all allocated an ID number from 0 to 7. In the case of our Zip drive we have the choice of selecting ID 5 or 6 via the little switch at the back. As this is our only device either ID will work but I will be using ID 5 for the rest of this guide.

Zip 100 Drive with termination set to ‘on’ and ID set to ‘5’.

The other peculiarity with SCSI chains is that both the first and last devices on the chain have to be ‘terminated’. The Squirrel SCSI adaptor is actually classed as the first device (ID 0) and is already terminated. The Zip drive will be the last device on our chain and so must also be ‘terminated’. Often times on other devices you would have needed to plug a physical Terminator (a bit like a blank plug) into an empty socket to terminate a device. Fortunately the Zip drive has the circuitry built-in and selectable via the switch on the back.

Once the switches are set correctly (as shown in the image above) the Zip drive can be hooked up to the Squirrel and we are ready to proceed onto the next phase.

My Zip Drive (sat on top of my MorphOS machine).

Getting the Zip 100 Drive to work with Amiga Workbench

I’m using AmigaOS 3.1.4.1 but I would assume this will work just as well with 3.0 and above.

To get the Amiga to actually read and write to our Zip disks we need to create a ‘Mountlist’ for them. It actually took me a few days of tinkering with different mountlists off Aminet before I found one that would actually work reliably. I’ve successfully formatted several dozen disks with this mountlist so I’m pretty happy with it now.

Now I could have created a mountlist that would allow the reading of PC formatted disks but as Zip drive PC compatibility ceased with with the demise of Windows XP I didn’t feel it would be very useful. Consequently this mountlist is purely for Amiga use.

Now as you will discover, there is no mountlist on your Amiga for Zip disks, even in the storage directory, so we must make our own. To do this we need to copy a spare one from the Storage/DOSDrivers directory and place it into the Devs/DOSDrivers directory. I used the AUX mountlist but any of them will do. This can be achieved by opening up a Shell prompt and typing the following commands:

copy sys:storage/dosdrivers/aux sys:devs/dosdrivers/ZIP0

This copies the AUX mountlist to the correct location and renames it at the same time.

We also need the icon file so press cursor up to bring back your last command and edit it to look like this:

copy sys:storage/dosdrivers/aux.info sys:devs/dosdrivers/ZIP0.info

Now open up that newly created ZIP0 file in the editor of your choice. If you don’t have one then simply enter this command into the Shell to use the built in text editor:

ED sys:devs/dosdrivers/zip0

Delete all the existing text in the file and then enter the following exactly as shown below:

FileSystem = L:FastFileSystem
Flags = 0
Surfaces = 2
BlocksPerTrack = 64
SectorSize = 512
Mask = 0x7ffffffe
MaxTransfer = 0x0ffffffe
Reserved = 2
Interleave = 0
LowCyl = 0
HighCyl = 1535
Buffers = 50
BufMemType = 0
StackSize = 600
Priority = 10
GlobVec = -1
DosType = 0x444f5301

It should look like this on the Amiga:

ZIP0 Mountlist entries

Once you’ve entered everything above, triple check it. Once you are certain it is correct make sure you save the edited file!

We’re not quite done yet. We need to add a few Tooltypes to provide the Amiga with a bit more info to go on. Click on the ZIP0 icon and select ‘Information…’ from the Icon Window and edit the Tooltypes.

Delete any existing entries that may be in the Tooltypes window and replace them with these:

DEVICE=squirrelscsi.device

ACTIVATE=1

UNIT=5

DONOTWAIT

It should look like this when you’re finished:

ZIP0 Icon Tooltype entries

Check what you’ve entered is correct and then click save and reboot your Amiga. Pop a Zip disk in the Zip drive and it should pop up on the desktop looking like the image below. If it doesn’t then you will need to go back through the above and check you’ve got everything right.

An uninitialized Zip disk.

Zip disks come formatted for Macs/PC’s so they will need formatting before they are useable on the Amiga. Just format them as you would any regular floppy disk. Click on it and select ‘Format Disk’ from the Icon menu. Give the disk a name if you like or leave it as ’empty’ (you can always change it later). The rest of the settings can be left as they are. I strongly recommend you do a full format as these disks are old now – better to discover any issues with them before you start to use them rather than later on when it may be too late! Better yet use IOTools – more about this later.

The Workbench Format Disk window for a Zip disk.

It takes around 5 minutes to do a full format of a Zip disk so go and have a cup of tea while it finishes.

Formatting progress indicator.

Providing there are no errors you should be presented with a nice formatted disk icon.

Formatted Zip disk icon.

It may look like an ordinary floppy disk, but on closer inspection you can see that this disk has nearly 100MB of space available.

Zip disk with 96M free space.

Iomega Tools

Now by all means we could leave things here, I mean everything works as it should after all. However I’d recommend installing Iomega Tools as well. This software provides a lot of extra functionality that would otherwise be lacking from the Amiga experience. Things like a software eject, password protecting disks and access to hidden drive settings.

One of the main reasons I like this software is that it offers the ability to override the default sleep time of the Zip drive. By default your disk is kept spinning with the heads in constant motion for 15 minutes before spinning down after any disk activity. This will generate a lot of unnecessary wear and tear on both the disk and drive which is something we should be avoiding. Zip drives aren’t getting any younger after all!

IoTools Main Window.

You can download this free software off Aminet. There is no installer – just copy the main IoTools program to either your WBStartup (recommended) or your Workbench Tools directory.

WBStartup is recommended so that the software is always running. Things like the sleep timer settings are stored in the software itself so it needs to be running to have any effect. You can still install it elsewhere if you don’t intend to use the Zip drive all the time and are happy to run it manually whenever you do use it. Alternatively you can select ‘Park Drive’ and ‘Start Disk’ to manually stop and start the drive respectively.

Amiga IoTools Settings Screen.

You need to configure the settings of your SCSI device and drive for the software to work fully. The settings that worked for me are shown in the image above. Most boxes are set to their default. The ‘Device’ setting which is truncated in the image is ‘squirrelscsi.device’. If you do have the software running every time you boot your Amiga then you might want to tick the ‘Open Iconified’ box which will help keep your Workbech screen tidy.

Drive Settings is where the sleep countdown is located. I recommend a time of 5 minutes as a good compromise between convenience and preservation.

Zip Drive Sleep Settings.

The Lock or Unlock Media screen is where you can password protect your disks or remove the protection completely.

Password protect your Zip disks here.

The Format Disk window is incredibly useful and is what I used to format all of my disks. Choose the Format and Verify option and it will do a full format whilst also performing a thorough check of the Zip disk, mapping out any bad sectors as it goes. This takes approximately 9 minutes per disk which is a lot longer than even the full format I mentioned earlier. However I feel it is worth the investment of time for the peace of mind it offers.

Format and Verify option will make sure your disks are in good shape.

The Disk Status screen offers some interesting stats about the currently inserted Zip disk…

Amiga IoTools – Disk Status Screen.

As does the Drive Status screen.

IoTools Drive Status Window.

If you have a disk in the drive the ‘Run Diagnosis’ option will do a thorough check of the drive to make sure it is operating correctly (it doesn’t delete any info on the disk).

IoTools Drive Diagnosis complete.

Amazingly the software is still supported too – it was last updated in May 2020. I even contacted the author, Thomas Richter, with a query and he got back to me within minutes. How’s that for Amiga support!

Zip Drive is now part of my A1200 setup.

Anyway I really enjoyed my little Zip drive adventure and am making good use of it to organise my collection of Amiga ADF’s, Music and more.

I do hope you found the guide useful… it has taken me many an evening and weekend to pull all the info together and get it into a cohesive post. If you found it interesting/helpful then please let me know in the comments below!

Installing Amiga OS 3.1.4 – Part 5 – Finishing Touches

27th August 2020

Steven

Amiga

27 Comments

In parts 1 through 4 of this guide I covered everything needed to install Amiga OS 3.1.4 on an Amiga 1200 from scratch. However there are still a few things that can be done to improve the installation.

I’m afraid this post ended up a lot longer than I anticipated so I’ve put some links below that will take you straight to each section.

Fancy Glowicons

If you’ve seen any screenshots of Amiga OS 3.1.4 on the internet you may well be wondering why we haven’t got any fancy new icons with our Workbench install. Well for some reason the installation of these was never automated so this is something you must do yourself. The good news is that these icons are tucked away on the ‘Storage’ disk and can be installed manually quite easily.

Boot your Amiga up and then insert the ‘Storage’ disk into the drive. Next, open up the Shell and enter the following command:

copy storage3.1.4:glowicons/#? sys: all

This will copy the icons off the floppy disk and onto your Amiga’s system partition.

This command will copy the new icons onto your Workbench drive.

There are quite a lot of icons to copy over so it will take a little while to complete. You should see a load of text scrolling up the window before the command prompt finally returns.

When you see the Workbench:> prompt appear the icons have finished copying over.

At this point you can close the Shell and reboot your Amiga.

New Workbench 3.1.4 Icons!

When it reboots you should be greeted by much more colourful Workbench screen filled with lovely new icons. You may need to spend a little time re-arranging them to your liking but they definitely look a lot better than the old ones!

Here you can see all the new Preferences Icons.

Setting the Screen Mode

By default your Amiga will have configured the screen mode to either PAL (640×256) or NTSC (640×200) High Res mode. This results in a very stretched looking Workbench screen and doesn’t give you much space to work with either.

Vertically stretched Workbench screen in PAL Hires mode.

Assuming your monitor will support it, I recommend changing the display mode to High Res Laced. This doubles the vertical resolution providing the correct aspect ratio for your Workbench screen and twice the space for icons and windows.

Amiga Screen modes

And here’s what Workbench looks like once the screen mode has been changed – much better!

So much more space and our icons are now the correct shape!

I’m very lucky with the screen I’m using with my Amiga. It’s an old LCD TV with a 720P screen. It supports RGB SCART and is able to display all of the standard Amiga screen modes. What’s more, because it’s an LCD panel, interlaced modes do not flicker like they used to do on CRT monitors. This means I can get all the benefits of the extra resolution that interlaced modes offer without any of the negatives! Twenty years ago I would have needed a very expensive Multiscan monitor or a flicker-fixer/scan-doubler to achieve this (or have to put up with the flicker!).

Overscan Settings

I noticed something a bit odd after installing Workbench… my screen wasn’t centred and there was a weird border on the left, top and bottom of the screen. Basically dead space that I wasn’t able to utilise… until I cast my mind back 25 years and remembered about overscan border settings with CRT monitors.

Amiga Preferences.

In a nutshell the overscan settings were a way to tweak your display to maximise the available screen space. Most CRT’s were housed in plastic cases that partially shrouded the outer edges of the tube by varying degrees and thus hid a part of the image. Typically beyond the limits of the designated display area the borders used to be black and you would adjust the overscan settings to get rid of this and have as much ‘picture’ filling the screen as possible.

Modern TV displays and monitors no longer have overscan as they are able to display 100% of the image thanks to flat LCD panels so we should be able to get our Amiga to fill that display completely.

To achieve this load up the ‘Overscan’ preferences to get the display shown below.

Amiga Overscan Preferences

Click on ‘Edit Text Size’ to bring up the overscan adjustment screen shown below.

Amiga Overscan Adjustment.

As you can see from the above image, the borders I was seeing on my screen are perfectly illustrated here. To get rid of them what we need to do is click on those black squares and drag them to the very edge of the outer box like in the image below.

Amiga Overscan Settings.

If you notice the resolution of the screen has increased from 640×256 up to 692×275 which is a nice bonus. Click OK to save these settings and then click on ‘Edit graphics size’ and repeat the exact same process. Finally click on ‘Save’ to ensure that these settings are stored permanently.

Look ma, no borders!

Amiga OS 3.1.4.1 Update

Amiga OS 3.1.4 was released in 2018 and in 2019 a small update (3.1.4.1) was released which fixed a number of minor bugs. This update can be found on the appropriately named ‘Update 3.1.4.1’ disk that we created back in Part 1.

Starting the 3.1.4.1 update process.

Pop that disk in the drive and then look inside the Install directory and choose the installer in the language of your choosing. Next, run it and click on ‘Proceed’.

Choose an installation mode.

Now you must select the installation mode. As this is a straightforward upgrade I chose Novice.

Choose your language.

Then the language required for the install…

Installer doing its thing.

After which the update started to install. I think it took around a minute to complete.

Installation complete.

When the files have finished copying across a new window will appear to confirm the install has completed. Hit ‘Proceed’ and then reboot your Amiga.

We’re not quite finished with this update though as there is also a FastFileSystem v46.20 upgrade to perform which we will tackle next.

Installing FastFileSystem Patch 46.20

To begin this part of the upgrade process we need to launch HDToolBox (found in the ‘Tools’ directory) and then click ‘Partition Drive’. If you have more than one drive shown here then make sure you select the one you wish to update.

Amiga HDTooBox Window

When the partitioning window appears select your boot partition (the one on the far left) and then tick the ‘Advanced Options’ box. A bunch of extra settings should appear below as you can see in the next image.

Setting Direct SCSI Transfer option for DH0:

Now what we need to do is make sure that the ‘Direct SCSI Transfer’ box is ticked for DH0. (Mine wasn’t).

Direct SCSI Transfer

We then need to ensure that this is also ticked for each of your other partitions. To do this just click on each of your partitions on the top bar in turn and tick the ‘Direct SCSI Transfer’ box for each one.

This slideshow requires JavaScript.

The next task is to apply the FFS patch to the drives. To begin the process click on the ‘Add/Update…’ button at the bottom of the window.

Add/Update button.

This should bring up the following window that lists all of the available file systems you can use.

File System Maintenance Window

Now the readme supplied with the update seems to be rather vague here. The first time I tried this update myself it didn’t work. In the above window you can see two file systems listed. Custom File System and Fast File System. What actually needs to appear here is ‘International (FFS)’. So in the end to get this to work I clicked ‘Add New File System…’

Don’t touch this.

I didn’t change the default path in the box that popped and also accepted the following details that popped up without altering them (below image).

Don’t touch this either.

After I clicked ‘OK’ I was dropped back to the System Maintenance screen and this time my file system was listed at the top with the correct version number.

International (FFS) Now on the list.

I clicked ‘OK’ and was dropped back to the initial screen where I could see that there were changes waiting to be written back to the drive.

HDToolBox – with changes to be saved to drive.

After clicking ‘Save Changes to Drive’ I got a very scary message warning me that it was going to destroy all the data on my drives.

Dire warning message!

However the readme file does warn you about this message and insists that it can be safely ignored. Feeling suitable comforted I pulled the trigger and clicked ‘continue’ then rebooted my Amiga. Happily it rebooted without a hiccup – phew!.

The last thing to do was do a quick test to make sure the update had been successfully applied. To do this I opened a Shell window and entered the following command.

version dh0:

Version DH0 command

The version command returned ‘Filesystem 46.20’ which was spot on. Mission accomplished.

Fixing my GlowIcons!

There now remained just one nagging problem – throughout my whole time preparing this guide the appearance of my icons bugged me. They didn’t look as good as the ones in the screenshots I’d seen. My icons were displayed on a sort of background ’tile’ which should have been transparent. Basically they looked ugly and needed sorting!

Amiga Workbench Preferences Screen

After rummaging around the Preferences directory I eventually found ‘Workbench Preferences’ which contained the settings I needed to modify. On the right hand side is an Icons section and for some reason mine was set to ‘Poor Quality’ and ‘Large Border’. I have no idea why this was the case but I changed them immediately to ‘Best’ Quality and set the Border Size to ‘No Border’. I saved the settings and like magic my Icons were transformed into the beautiful little works of art they should have been all along.

I have to confess I don’t remember this particular preferences program from back in the day which is why it took me a while to figure it out. It could be a new feature of Amiga OS 3.1.4… or I might just have completely forgotten about it!

Amiga WBPattern Preferences Screen

At this point I also decided to throw on some wallpaper to brighten up my desktop. This is easily done by heading to the WBPattern Preferences and setting Background Placement to ‘Workbench’ and Type to ‘Picture’. Then it’s just a matter of clicking ‘Select Picture…’ and browsing to an image of your choice. Amiga IFF images of 256 colours or less work best here as they load instantly and don’t gobble too much of your precious Chip RAM. Pictures using over 256 colours will also be dithered which spoils their appearance which is another reason to choose wisely.

A few people have requested that I share the wallpaper I used for my Workbench backdrop so I’ve included the .iff image to download below.

AmigaWallpaper.zip

Incidentally if you are looking for a way to view Amiga .iff files on your PC then I highly recommend XnView Classic (shown below). Not only can it display .iff files but it can convert them to other more modern formats and vice versa. It’s completely free for personal use and can be downloaded here.

XnView Classic displaying an Amiga IFF image on a PC.

And that pretty much wraps up Part 5 of my Amiga OS 3.1.4 installation guide. Enjoy the fresh lick of paint and tune-up this gives your Amiga!

Installing Amiga OS 3.1.4 – Part 4 – Installing Workbench

23rd August 2020

Steven

Amiga

81 Comments

Having created the physical floppy disks in Part 1, installed the 8GB CF card and ROMs in Part 2 and partitioned the CF card in Part 3 it is now time to look at installing Workbench 3.1.4.

The first thing to do is boot up the Amiga using the 3.1.4 ‘Install’ disk. Once the desktop has loaded open the Install disk and look inside the ‘Install’ directory. There will be a bunch of different language installers so run the one that you need, which for me was the English one.

Various Workbench installers in different languages…

This will load up the Installer and give you a little introduction about what it will do. Click ‘Proceed’ to begin.

Starting the installation.

Now you will be presented with another window that will allow you to add additional languages to an existing install. As this is a clean install just click on ‘Install Release 3.1.4’.

Requester giving option of installing another language.

Next you need to choose the installation mode – I chose Intermediate.

Selecting Installation Mode.

Installation Mode?

After selecting either Novice, Intermediate or Export User and then ‘Proceed with Install’ you are presented with the Installation Options screen. Here you can choose to ‘Install for Real’ or ‘Pretend to Install’. I believe this could well be unique to the Amiga? I certainly don’t recall ever having the option to do a pretend install on any other system. It can be useful to perform a pretend install on occasions as it lets you discover any potential issues and gives you a chance to fix them before committing to the actual install. However as this is a clean install we’re going to select ‘Install for Real’ and then boldly hit that ‘Proceed’ button.

Install for Real… or Pretend?

You should see a brief message about ‘Release 3.1.4’ being installed on the Workbench partition. This is because it has detected it is the first bootable partition – if you gave yours a different name back in Part 3 then it will be shown here.

This is where the actual installation starts.

Click the ‘Yes’ button to begin the installation and then choose which language(s) you want installing on the next screen. For my install I just wanted English so just left that option ticked.

Pick what languages you want installing.

Next you need to select what printer drivers you want. I selected them all because space is not an issue and you never know what you might want to hook up to your Amiga in the future.

Choosing a which printer drivers to install.

Another decision needs to be made on the next screen about which keymaps are required. Or in other words what language setting do you want for your keyboard. In my case as I live in the UK I chose a British layout before clicking ‘Proceed’.

Choosing a keyboard language or ‘keymap’.

Let the Disk swapping commence!

After a few moments you will be asked to insert the Workbench disk. There should be no need to click proceed, your Amiga should detect the presence of the swapped disk and continue automatically.

Insert Workbench Disk Screen

A bunch of files will be copied across to your new System drive.

Workbench install – copying files.

And then you will be asked to insert the Locale disk.

Insert Locale Disk Screen

Which will copy more files across… before asking for the next disk – Fonts.

Insert Fonts Disk Screen

Then the Storage disk…

Insert Storage Disk Screen

And then finally it will ask you to re-insert the Install disk.

Insert Install Disk Screen

Now at this point I was faced with the following warning as I had an accelerator installed with a 68030 CPU. I was able to click ‘Proceed’ and carry on but a version of this warning would pop up every single time I booted up my Amiga until I sorted it. Click here and then head down to the bottom of the page for information on how to resolve this issue.

CPU Warning.

And that should be your Worbench 3.1.4 install complete!

Congratulations – Workbench Install Complete!

Remove the floppy disk from your Amigas drive and reboot it. If all has gone to plan your Amiga should silently boot into Workbench 3.1.4 looking a lot like the photo below with all your partitions visible on the desktop.

Amiga Workbench 3.1.4 Screen.

And that concludes Part 4 of my Amiga OS 3.1.4 installation guide – Installing Workbench.

Now we could leave it here, after all we now have a fully operational installation of Workbench 3.1.4 on our Amiga. However there are a few more things we can do to tweak and improve the install and I will cover these in Part 5.

Installing Amiga OS 3.1.4 – Part 3 – Partitioning a Compact Flash Card

23rd August 2020

Steven

Amiga

Add comment

Having created the physical floppy disks in Part 1 and installed the 8GB CF card and ROMs in Part 2 it is now time to set about partitioning and formatting the compact flash card so we can install Workbench 3.1.4 on it (in Part 4).

To start the process of partitioning a compact flash card I booted my Amiga off the 3.1.4 Install disk. Once it booted I ran the HDToolBox program found inside the ‘HDTools’ directory.

HDToolBox Program

This brings up the window below where you can see all of your installed hard drives. Mine is listed as a SCSI unit which is normal as this is how the Amiga sees the internal IDE controller.

Amiga HDToolBox Main Window

Clicking on ‘Change Drive Type’ brings up the window below. As this is a new CF card there is nothing on it yet so you must click on ‘Define New’.

Amiga HDToolBox – Defining a New Drive

Which brings up the the ‘Define a New Drive Type’ screen. You need to click ‘Read Configuration’ at this point which will bring up another message. Simply click ‘continue’ to move on here.

Informational Message

The software will then take a moment to scan the CF and identify the size and parameters needed to access it. After the scan has completed it will display this info in the window as seen below.

Drive Parameters

Now you can simply click ‘OK’ to get back to the ‘Drive Type’ window and then click ‘OK’ once more. At this point you will be warned ‘Are you sure you want to change the drive type for the current drive?’ Clicking ‘Continue’ will return you to the main HDToolBox screen once more.

Back to the main screen but now with a ‘Changed’ drive status.

Now that HDToolbox knows the ins and outs of our CF card it is time to partition it into drives. Of course we could just make it one big 8Gb partition, after all Amiga OS 3.1.4 now natively supports large drives. However I always like to split mine into at least 2 partitions to keep things organised.

To start this process click on ‘Partition Drive’.

Select ‘Partition Drive’.

Which should bring up the partitioning window as shown below.

I chose to make my first partition 500MB, this will be my System/Workbench drive. To select the size you simply drag the little triangle pointer and slide it along the bar. It’s virtually impossible to size a partition exactly so just get it as close as you can.

You need to give the partition a name – I called it DH0. I also ticked the box to make it bootable as this is the first partition and will be the one the Amiga will boot off.

Creating the first partition.

To create another partition you click ‘New Partition’. Don’t be tempted to click the ‘OK’ button until you have finished creating all your partitions. For my second partition I called it DH1 and made the size approximately 1.5GB. I will be using this to install applications and save documents to. I will probably keep a small selection of music on this drive too.

Creating the second partition.

I left my biggest partition for last so it could use all of the remaining space on the card. This worked out at a little less than 6GB in total. I called this partition DH2 and this will be where I install WHDLoad games.

Creating the third partition.

You can click each of your partitions in the bar to check their details. Once you are happy that they are all exactly the way you want them to be, hit ‘OK’. You should then be back to the main HDToolbox window.

HDToolBox with ‘changed’ drive status.

You must now click ‘Save Changes to Drive’ for all the settings you have configured up to this point to be written to the disk (CF card). The window should then change to look like this:

HDToolBox back to ‘Not changed’ status.

Congratulations! Your new Amiga drive has now been prepped and partitioned! The final step is to format the partitions. To do this you need to reboot the Amiga whilst leaving the Install disk in the drive so it can boot off it.

The three partitioned but currently ‘uninitialized’ drives created earlier.

When your Amiga has finished rebooting you should see a screen similar to the one above. You will notice that the partitions show either as ‘Uninitialized’ or just as a weird name (or both in my case).

The Format Disk menu item.

They now need to be formatted so that the Amiga can actually use them. To format a partition you just click on its icon and then select ‘Format Disk’ from the ‘Icons’ menu.

Formatting and Naming DH0.

In the above example I called my DH0 partition ‘Workbench’ but you can call yours whatever you like. If you are interested in the new long file names feature of 3.1.4 now would be a good time to select that tick box.

First format warning…

Make sure you select ‘Quick Format’ or you’ll be waiting a very, very long time for the format to finish. You will get a couple of scary warnings that give you an opportunity to back out if you’ve accidentally selected the wrong disk to format.

Second and final format warning.

Click ‘Format’ in response to both of the warning messages to seal the deal. A few seconds later a drive on your newly partitioned and formatted compact flash card should appear on the workbench screen. Now simply repeat this process for each partition you created earlier.

And that concludes Part 3 of my Amiga OS 3.1.4 installation guide – Partitioning a Compact Flash Card.

I must admit I had originally intended to include the Workbench install in this part too but decided against it as I thought this post was long enough already. Therefore I will be covering the installation of Workbench in Part 4 shortly.

Installing Amiga OS 3.1.4 – Part 2 (Fitting a CF Card & Kickstart 3.1.4 ROMS)

18th August 2020

Steven

Amiga

67 Comments

Having created the physical floppy disks in Part 1 of this guide it is now time to fit the IDE Compact Flash adapter and the 2 Kickstart 3.1.4 ROMS.

Fitting the IDE Compact Flash Adapter

For this I needed to open up my A1200 to gain access to the mainboard.

Location of the 5 case screws.

Removing the top half of my A1200’s case was just a matter of turning it over and removing five screws. I’ve circled their locations in the photo above. There were three along the front edge and one each side of the case. The two rear edges of the case are held together by some little lugs and recesses in the case itself.

Pin 1 of ribbon cable aligned with pin 1 on mainboard.

Fitting the IDE Compact Flash adapter simply involved fitting the 44 pin cable connector to the IDE header on the board. Notice how the coloured strip of the ribbon cable aligns with PIN 1 on the board. I chose an 8GB CF card for my install as Workbench 3.1.4 now natively supports large drives. However a smaller card would work just as well. I think my original A1200 had an 80MB (yes I do mean Megabyte!) drive back in the 90’s so 8GB is an insane amount of storage!

Foam pad fitted to insulate underside of adapter.

As the compact flash adapter has lots of solder pads on the base, I stuck a thick foam pad on the underside. This will ensure that the contacts don’t short out when sat on top of the metal drive bracket. (This drive bracket would have been used to house a 2.5″ IDE HDD back in the day).

CF adapter in it’s final resting place.

Removing the old Kickstart ROMS

Luckily the Kickstart ROMS have their own little cut-out in the metal RF shielding so there is no need to remove the shield to access them.

The original Kickstart 3.0 ROMs. Note the empty socket pins on the left!

I used my trusty chip puller to remove these, gently alternating pressure from one side to the other until they popped out. You could use a small flat bladed screwdriver to do this. Make sure to alternate from side to side, lifting the chips one millimetre at a time so you don’t bend the pins. If you want to make life even easier, use an old screwdriver and bend the blade 90′ at the end to make getting it under the chip easier.

Pulling out the Kickstart 3.0 ROMS.

Fitting the new Kickstart ROMS

With the old ROMs removed it was time to fit the new ones. After making sure the pins would line up OK (they were splayed out a little too far) I began to fit them.

It’s vitally important they are fitted correctly and besides the usual static precautions there are three things to watch out for.

The chips have to go in the right sockets. The chip marked as ‘HI’ must go in the front slot. The chip marked ‘LO’ must go in the rear slot.
The chips must be oriented correctly. The end with the notch must be fitted so that it is on the same side as the notch in the socket.
The sockets have 42 pins whereas the chips only have 40! You must make sure to leave the 2 pins on the left side of each socket empty.

The 2 new Kickstart ROMS fitted correctly.

Thankfully testing the ROMS is pretty straightforward. Flicking on the power should display a brand new boot screen. That boing ball is definitely new! You can also see the updated ROM version and copyright message.

The brand new Hyperion Amiga boot screen.

That concludes Part 2. In Part 3 I will deal with partitioning and formatting the Compact Flash card.

Installing Amiga OS 3.1.4 – Part 1 (Obtaining the Disks)

16th August 2020

Steven

Amiga

4 Comments

For my ‘new’ Amiga 1200 I decided I wanted to have the latest Workbench running on it so I ordered myself a copy of AmigaOS 3.1.4 from Sordan in Ireland. It arrived a few days later in a small cardboard box and consisted of a ROM Installation Guide, 2 Kickstart chips and a bunch of labels for you to stick to your own Amiga OS 3.1.4 Disks.

This is what you get when you purchase Amiga OS 3.1.4

Registering my Purchase

To actually obtain digital copies of the disks I had to register my serial number (found on the top of the Kickstart ROM’s) on the Hyperion Entertainment website. After doing that I was able to download a bunch of ADF files and a few other things (Wallpapers, Icon packs and documentation mainly) on my PC.

Time to crack open a nice box of 3.5″ Floppies.

It would have been nice to have received the disks in the box but it’s no real hardship creating my own and it cuts down the price quite a lot. I love working with real floppy disks anyway, the tactile feel of them in use and listening to the whirring of the drive as it accesses them*.

*I hate working with grotty, mouldy, faulty old disks that end up giving me nothing but aggravation and a headache.

You don’t see this much any more…

I decided to use my trusty Amiga 500 to create the disks as it has an SD Card reader that makes transferring the files across from my PC a doddle. Once I’d copied the ADF files over I loaded up my favourite ADF software, GoADF and dug out a box of new 3.5″ DS DD floppy disks and set about creating my 6 Workbench disks.

GoADF

Creating the Workbench Disks

I started with the Workbench disk first, selecting it from the list of ADF files provided. Double-clicking the name of the ADF loads the image into the software.

Here we can see all the Amiga OS 3.1.4 Disk images in GoADF.

Alternatively you can click the ‘Load image’ button on the bottom left of the screen.

Load (ADF) Image.

As I wanted to create a physical disk from the ADF files I selected ‘Image to disk…’

To write ADF images to a real floppy you must select the ‘Image to disk’ option.

Which loads up the disk creation window. Here you can select which drive you want to use and whether you want to format and/or verify the disk.

My disks were IBM PC formatted hence the ‘not a valid DOS disk’ warning.

I opted to both format and verify the disk. You simply can’t be too careful when working with floppy disks these days. Most DS/DD floppy disks have to be at least 20 years old by now as new ones haven’t been manufactured in a long time.

At this point it might be a good time to check that the disk you have inserted really is the one you want to use!

Writing the First Disk

Clicking ‘write image to disk’ brings up the obligatory warning that the disk will be overwritten. Clicking ‘yes’ begins the process which starts off with the disk being formatted.

Formatting the disk…

GoADF features a neat virtual representation of the floppy disk marking each sector white as it’s formatted…

Writing the data to the disk…

Then blue as the data is written to it…

Verifying the disk…

And finally places a small black dot in it after the data has been successfully verified. A couple of minutes later a little box appears to confirm the disk has been created successfully.

Hurrah – one down, five to go!

And here’s the completed disk with it’s snazzy label affixed.

Amiga OS 3.1.4 Workbench Disk.

Now it was just a matter of repeating the process for the other 5 ADF’s to give me a complete set of Workbench disks.

A full set of Workbench 3.1.4 floppy disks!

However there’s a couple of other disks that needed creating – ones that no labels are provided for. The first is the ‘Modules Disk’ and the second is a new ‘3.1.4.1’ update that has recently been released containing the latest Workbench bug-fixes. The update disk was a separate download from the Workbench disks but is provided free for registered users.

The extra disks needed. Sadly no professionally printed labels for these!

In Part 2 I will cover installing the ROM chips and performing a clean install of Workbench on a new CF/HDD.

Blizzard 1230 MkIV Accelerator Card

16th August 2020

Steven

Amiga

1 Comment

I recently managed to pick up a nice Blizzard 1230 MkIV accelerator off eBay which arrived a couple of days ago. I reckon I was probably just as excited to get this one in 2020 as I was back in the 90’s when I got my first one!

After opening it up I gave it a good visual once over and everything looked to be in good order. Not sure why the markings have come off the top of the chips but I won’t see them once it’s installed anyway.

Some Information about the Blizzard 1230 MkIV

My 1230 was made by Phase 5 Technologies which is the original manufacturer of the cards. Unfortunately Blizzard went out of business so later cards were manufactured by a company called DCE. Ironically it looks as though DCE still exists to this day making electronic circuit boards!

I’m guessing this was manufactured some time in 1995 looking at the board.

As standard the Blizzard 1230 MkIV comes with a 50Mhz Motorola 68030 Processor and can be fitted with a single 72 pin SIMM up to 128MB in size. Mine came fitted with a 64MB SIMM. The exposed edge connector is where an optional Blizzard 1230-IV Fast SCSI-II controller module can be attached. The SCSI module actually incorporates a second 72 pin SIMM slot meaning you could theoretically add a whopping 256MB of FAST RAM to your A1200 if you wanted to! Of course now I want to do just that but the SCSI modules are super rare these days!

The Motorola 50Mhz 68030 CPU (on the right) and 50Mhz 68882 FPU (left).

I made sure I got one with the FPU installed as this was not included as standard. These were never strictly necessary and most software didn’t benefit from having one. However VistaPro (one of my favourite programs) is just one such title that relies heavily on having one. The FPU really makes a significant speed difference for programs like this that involved performing a lot of complex mathematical calculations.

View of the reverse side of the board.

Fitting the card

I’d forgotten just how snuggly the Blizzard 1230 fitted inside an A1200. After triple-checking it was correctly aligned I needed to gave the card a worryingly forceful push before it finally clicked into position.

This is how the card looks fitted inside my A1200. The edge connector, visible on the upper left, is for the optional SCSI module. If I ever come across one I’ll add it to my setup for sure.

Of course the real moment of truth was turning the Amiga on. Happily this proved to be completely uneventful. Workbench booted up without a hitch and reported 65,957,656Mb of Fast RAM which was a great start.

Workbench Screen showing Chip and Fast RAM levels.

From 0 to 65,957,656Mb. A good start!

Speed Test

The next test was to load up the classic Sysinfo and make sure the CPU and FPU were correctly identified, which they were. Of course you can’t load Sysinfo and not run a quick speed test! My Blizzard equipped Amiga topped out at 9312 Dhrystones, or 9.72 Mips. Basically twice as fast as a 25Mhz A3000 which is exactly what you would expect.

Of course it’s nowhere near as fast as my Vampire equipped A500 and it actually cost quite a bit more too. But you know what? I don’t care. This just ‘feels’ right. The best way I can describe it is if you imagine upgrading a classic car. The Blizzard is like fitting a period authentic performance exhaust and carburettor to the engine whereas the Vampire is like replacing the whole engine with an electric one. Don’t get me wrong, the Vampire is an amazing piece of hardware and you can’t beat it in terms of value for money. However absolute power is not my goal here… it’s having an authentic Amiga experience.

SysInfo Speed Report.

Real Time Clock Test

Anyway enough of that. There was one final test that would take a little longer to complete. The Blizzard incorporates a 3V rechargeable battery backed clock for keeping track of the date and time. However when I plugged the card in the date/time were completely wrong. The seller told me the card hadn’t been used in years which is why he was selling it so this wasn’t unexpected.

To test the battery I set the date and time correctly and then left the Amiga turned on for a couple of hours before going to bed. This would hopefully give it a chance to get some charge before turning it off for the night. Booting it up the following evening revealed it had retained the correct time so the battery was still working! Of course the battery may no longer hold enough charge to last for extended periods but for now I’m happy that everything appears to work perfectly!

Amiga keeping the correct date and time!

MMU Library

With the card installed and tested there was just one niggle for me to sort out. Every time I booted my A1200 I was getting the following error about no MMU library being installed:

“This system is running from a 32-bit CPU (68030, 68040 or 68060) which may require specific CPU libraries to be installed in the LIBS: directory of your hard disk.”

It then goes on to recommend you either install these files off the disk that came with your accelerator card or search Aminet. As I didn’t receive a disk with the card I went straight to Aminet and had a rummage around. Sure enough there was an MMULib.lha download for just such a scenario. I ran the installer and let it install an mmu.library and a bunch of 680×0 library files and then rebooted. And just like magic the error was gone – happy days!

Now I just need to get hold of that SCSI module!

Welcoming an Amiga A1200 into the fold.

11th August 2020

Steven

Amiga

4 Comments

Today the Lyonsden computer collection just got a little bit bigger with the arrival of a Commodore Amiga A1200 computer! 🥰 This is actually something I’ve been hankering after for a long time now. I’ve missed being able to play those old AGA games and also wanted to get back to using an ‘original’ machine. Not only that but the A1200 is just a more capable and expandable machine. It has an internal IDE interface as standard and a PCMCIA slot that can be used for a multitude of things. Wi-Fi and ethernet network cards, card readers, SCSI interfaces and so on. That AGA chipset is not just for games either, it provides a range of improved workbench screen modes that support up to 256 colours too!

View from the left.

The A1200 has been recapped already so hopefully it will provide many more years of faithful service now. It’s a really nice example and hasn’t been modified in any way which is how I intend to keep it. I’ve already heavily modified my A500 so hopefully I’ve scratched that particular itch well enough already!

View from the right. Original floppy disk drive fully intact.

The plan is to operate the Amiga A1200 just like I would have done 25+ years ago. That’s not to say I’ll be keeping it stock… oh no. But it does mean I won’t be fitting a modern FPGA accelerator into it for example. Whether I can operate it without a Gotek remains to be seen but I’m certainly going to try!

View from above.

Upgrades on the way…

I’ve already got a Blizzard MkIV 68030 accelerator on the way for it and a SCSI CDROM drive is sat on the desk ready to be hooked up too. These are both accessories that I had back in the 90’s and so meet my criteria for keeping things original. I also plan to fit a hard drive (well CF card) and install the very latest AmigaOS 3.1.4 on it too. Basically lots of new projects to look forward to!

View showing the serial number and silver Commodore label.

A look at Fusion #12

24th July 2020

Steven

Amiga, Commodore 64, Gaming

Add comment

Time to take a look through this months Fusion #12 magazine and give a little insight into what you can find inside it.

A look at the cover of Fusion #12.

As I’ve come to expect there’s a broad range of content this month. Topics include (non computer) games, toys, TV shows and of course computer games. Buckaroo is in the spotlight this month and is a game I played a lot with my mates during the 80’s. There’s also a look at merchandise from the TV show ‘V’ (and a look at the associated computer game too). I was glued to the TV every night when that show was on and remember being genuinely shocked when Diana stuffed a hamster into her mouth! Needless to say the article triggered many happy memories and reminded me of my teenage crush on Diana 😉.

Elsewhere there’s articles covering the Frey twins, the 1942 arcade game, Teenage Mutant Ninja Turtles, a flashback 1999 PlayStation chart and loads more.

Here’s a little peak at some of the stuff in this new issue:

This slideshow requires JavaScript.

Here’s the contents page so you can see what else features in this issue:

Fusion #12 Contents.

If you want to pick up a copy of Fusion #12 magazine then head on over to their website. The mag is £3.99 plus postage. Use the code ‘LYONSDENBLOG’ at the checkout to get a 15% discount. I will also receive a tiny bit of commission which helps towards the hosting costs of running this blog.

Amiga Future #145 – July/August edition out now.

11th July 2020

Steven

Amiga

Add comment

The latest issue of Amiga Future (Amiga Future #145) for subscribers has arrived. It features artwork from the game Fred’s Journey on the front cover.

Amiga Future #145 Front Cover.

What’s in this issue?

There’s a good mix of stuff in this issue as always with plenty of reviews to get stuck into. I’m a big fan of adventure games so was delighted to see a review of ‘The Queen’s Footsteps’. This is a brand new text adventure for the Amiga that had completely slipped under my radar. There’s also a complete guide to speed-running your way through Monkey Island 2 but that seems like sacrilege to me!

Issue #145’s cover CD.

There’s plenty of brand new game reviews in this issue. Fred’s Journey, Little Princess 1 & 2, Chips and Eye are all critiqued. Software wise there’s a review of Distant Suns 5 (which is included on the CD), Hollywood Designer 5 and RNOxfer, a new FTP client.

For the hobbyist there’s the regular AmigaOS 3.1.4 tips section, latest uploads to Aminet plus the latest Amiga news across 68K, OS4 and MorphOS systems.

Contents of Issue #145

The Cover CD

The main event for this issue’s cover CD is a full version of Distant Suns 5. This is a Desktop Planetarium and whilst I do having a passing interest in space, this software is on a whole other level entirely. Budding Patrick Moore’s may well get a lot of mileage out of it but sadly for me it was of no interest.

This is a preview of what you can expect to find in the latest edition of the long running Amiga Future magazine, Amiga Future #145.

Full version of Distant Suns on this issue’s Cover CD.

Below is a little peek at some of the stuff inside Amiga Future #145. If you’d like to purchase a copy then do please take a look here and support what is now the last remaining commercially printed Amiga magazine!

This slideshow requires JavaScript.

Never come across Amiga Future magazine before? Perhaps you’d care to take a look at some of my other Amiga Future magazine previews here.
